Features
|
CPU socket
Type
TDP
Material
Thermal paste
|
AMD® Socket SP3/TR4
1U Active
up to 225 Watt
Copper with VC Base
Shin-Etsu 7762 Pre-printed
|
| |
|
|
Technical Data
|
Fan size
Bearing
Voltage
Power
Fan speed
Air Flow
Air pressure
Noise level
|
80 x 13 mm
Double ball
12V
at 20%: 1.08 W
at 50%: 4.7 W
at 100%: 23.45 W
at 0~20%: 2000 ± 200 rpm
at 50%: 4900 ± 10% rpm
at 100%: 8600 ± 10% rpm
at 20%: 5.59 cfm
at 50%: 14.76 cfm
at 100%: 26.25 cfm
at 20%: 3.69 mm-H2O
at 50%: 25.28 mm-H2O
at 100%: 89.80 mm-H2O
at 20%: 23,3 dBA
at 50%: 43,5 dBA
at 100%: 62,2 dBA
|
| |
|
|
Environmental
|
Temperature
|
-10°C - 65°C (Operating)
-30°C - 70°C (Storage)
|
| |
|
|
Scope of delivery
|
|
Cooler
|
| |
|
|
Warranty
|
|
24 Months
|
| |
|
|
Logistic Data
|
Dimension
Net weight
Gros weight
Article number
GTIN
Packing unit
|
120 x 82 x 28,6 mm
0,555 kgs
0,500 kgs
88885597
0859300007130
1 pcs
12 pcs (carton)
|
