EN

A-24

High-quality CPU cooler to AMD® standard

GENERAL DATA
CPU Sockets AMD® Socket AM4/ AM5
TDP up to 120 Watts
Solution 2U Server
Cooling type active
Material Aluminum heatsink with heatpipe embedded
Fan Dimensions ∅ 60 x 28mm
Rated Voltage 12V
Bearing 2 Ball Bearing
Fan Speed At 20%: 1500 ± 10% RPM
At 50%: 3500 ± 10% RPM
At 100%: 7000 RPM
Fan Power At 20%: 0.60 Watts
At 50%: 2.16 Watts
At 100%: 7.20 Watts
Air Flow At 20%: 8.800 CFM
At 50%: 20.300 CFM
At 100%: 40.500 CFM
Air Pressure At 20%: 0.700 mm-H2O
At 50%: 3.600 mm-H2O
At 100%: 14.300 mm-H2O
Noise Level At 20%: 16.00 dBA
At 50%: 32.90 dBA
At 100%: 47.50 dBA
Fan Connector 4Pin PWM
OTHER DATA
Dimension 107 x 78 x 67mm
Warranty 24 months
SCOPE OF DELIVERY & FEATURES
Scope of delivery

CPU-Cooler

Retail packaging

Features

Thermal Grease Shin-Etsu 7762 Pre-printed

LOGISTICAL DATA
Shipping Unit 1 Pcs
Weight net = 0.400kgs
Item number 88885426
EAN-Code 4260455642545

Data sheet A-24
Download
Picture package A-24
Download

* You need a PDF reader to read these documents
* Pictures and drivers are always packed as Zip. You need to unzip them before using.
