SMA-6612
The SMA-6612 wall-mounted rack stands out for its low height of just 12U and a depth of only 600mm, offering a space-saving alternative compared to large and bulky server & network cabinets.
With a material thickness between 1.25 and 1.50 mm, the wall-mounted rack carries a total load of up to 40kg and also complies with the IP20 protection class. The rack is powdercoated in the colour RAL 9005 and can be closed both by the integrated door made of tempered glass and by the individually removable side panels. Cable inlets in the lid and in the floor also ensure a clean routing of the cables. Two optional 120mm fans, which find their place in the lid, support the case during ventilation.
- 12U and 600mm depth
- Total loading capacity of up to 40kg
- Meets protection class IP20
- Lockable glass door and side panels
| GENERAL DATA | |
|---|---|
| Unit | 12U |
| Width | 600mm |
| Depth | 600mm |
| Max. loading capacity | 40kg |
| Material front door | Tempered Glass |
| Opening angle of the doors | 180° |
| Colour | RAL 9005 |
| IP class | Fulfills IP20 |
| Dimensions (h/w/d) | 637 x 600 x 600mm |
| GUARANTEE / WARRANTY | |
| Warranty | 24 months |
| SCOPE OF DELIVERY & FEATURES | |
| Scope of delivery |
SMA-6612 Screw set 12 mounting screws and cage nuts 12 washers made of plastics Earthing screw Wall-mounting Assembly instructions (English, German for download) |
| Features |
1.25-1.5mm material thickness (cold rolled steel) The door can be hinged left or right Doors is lockable Side parts removable and lockable Space for 2x 120mm fans in the lid (Fan SWFAN 120mm/230V, Item No.: 88887269) Base and lid with cable inlets (screwed cover) Delivery is disassembled in one package |
| LOGISTICAL DATA | |
| Shipping Unit | 1 Pcs |
| EU palett | 14 Pcs |
| Weight | net = 23.52kgs gross = 26.47kgs |
| Item number | 88887254 |
| EAN-Code | 4260455644211 |
