Argus BPS-600
Argus BPS-600 – powerful and reliable!
The BPS series from Argus stands for powerful and reliable power supplies in the levels of 500W, 600W and 700W. To upgrade existing systems or to configure new ones, thanks to 80PLUS® Bronze 230V EU certification and state-of-the-art components, the BPS series will keep you up to date. To secure the built-in hardware and the power supply unit itself, we have not made any compromises and have equipped the power supply units of the BPS series with a total of five protective circuits (OPP, SCP, OVP, OCP and NLP).
When it comes to the variety of connections, we also kept an eye on the greatest possible efficiency and, with the exception of the 20+4pin connection, designed all other cable strands as flat ribbon versions - saving space and time when laying. The BPS-600 has four PCIe 6+2pin and six S-ATA connections available. With 50A on the 12V line, there is more than enough power available for potent hardware.
The overall package is rounded off by the smooth-running 120mm fan and the 36-month manufacturer's guarantee for the entire BPS series.
In the packaging of this power supply, we have almost completely dispensed with plastic. The power supply unit and accessories are packed in recycled paper instead of plastic bags.
- 80PLUS® Bronze 230V EU certification (up to 88.7% efficiency)
- 50A on the 12V line
- OPP, SCP, OVP, OCP and NLP
- 36 Months warranty
| POWER & EFFICIENCY | |
|---|---|
| Output | 600Watt |
| Efficiency |
|
| ATX-Version | 2.4 |
| CONNECTORS | |
| Mainboard 20+4Pin | 1x |
| 4Pin / 4+4Pin / 8Pin 12V | / 2x / |
| PCI-Express 6+2Pin | 4x |
| PCI-Express 6Pin | |
| IDE 4Pin (Molex) | 3x |
| S-ATA | 6x |
| Floppy | 1x |
| Fan monitoring | |
| Cable management | |
| OTHER DATA | |
| Fans / -size | 1x 120mm |
| Fan control | auto |
| Full Range Input | auto |
| 80PLUS® Certificate | 80PLUS® Bronze |
| Noise level | 22.1-39.4dB |
| Dimension (h/w/d) | 86 x 150 x 140mm |
| Warranty | 36 months |
| Safeties | OPP, SCP , OVP, OCP, NLP |
| SCOPE OF DELIVERY & FEATURES | |
| Scope of delivery |
Power supply Argus BPS-600 Retail package Manual (german, english) Power cord Screws Cable ties |
| LOGISTICAL DATA | |
| Shipping Unit | 1 Pcs |
| Packing Unit | 5 Pcs |
| EU palett | 210 Pcs |
| Weight | net = 1.77kgs gross = 2.13kgs |
| Item number | 88882178 |
| EAN-Code | 4260455645256 |
PERFORMANCE DATA
| AC Input | 100V/240V 47-63Hz max. 8/4A | |||||
| DC Output | + 3.3V | + 5V | + 12V | - 12V | + 5VSB | |
| BPS-600 | Max. Current |
15A | 15A | 50A | 0.3A | 2.5A |
| Max. Combined Power |
100W | 520W | 3.6W | 12.5W | ||
| 600W | ||||||
CABLE CONFIGURATION
