| POWER & EFFICIENCY | |
|---|---|
| Output | 300Watt |
| TFX-Format | |
| CONNECTORS | |
| Mainboard 20+4Pin | 1x |
| 4Pin / 4+4Pin / 8Pin 12V | / / |
| PCI-Express 6+2Pin | 1x |
| PCI-Express 6Pin | |
| IDE 4Pin (Molex) | 2x |
| S-ATA | 3x |
| Floppy | 1x |
| Fan monitoring | |
| OTHER DATA | |
| Fans / -size | 1x 80mm |
| Fan control | auto |
| Full Range Input | |
| PFC | active |
| 80PLUS® Certificate | |
| Dimension (h/w/d) | 65 x 85 x 175mm |
| Warranty | 24 months |
| Safeties | OVP, SCP , OCP, UVP, OS |
| SCOPE OF DELIVERY & FEATURES | |
| Scope of delivery |
Power supply TFX-300W Power cable |
| LOGISTICAL DATA | |
| Shipping Unit | 1 Pcs |
| Packing Unit | 10 Pcs |
| Weight | net = 0.975kgs gross = 1.18kgs |
| Item number | 88882144 |
| EAN-Code | 4260133128972 |
PERFORMANCE DATA
| AC ~ Input |
VOLTAGE | CURRENT | FREQUENCY | ||||||
| 200-240V | 3.15A | 50-60Hz | |||||||
| DC = Output |
+ 5V | + 3.3V | + 12V | - 12V | + 5VSB | PS-ON | POK | COM | |
| 8A | 6A | 22A | 0.3A | 2A | REMOTE | P.G. | RETURN | ||
| MAX | 45W | 264W | 3.6W | 10W | |||||
| 298W | |||||||||
| 300W | |||||||||
CABLE CONFIGURATION
