Features
|
|
Remote Monitoring by Webinterface or SNMP
Measure of current, voltage and power
Adjustable warning values
HTTP/HTTPS, DHCP, SNMP
E-Mail notification
User management
Measure of temperatur and humidity using the included sensor
|
| |
|
|
Input
|
Input voltage
Current
Connector
|
AC 100 - 240 V~, 50/60 Hz
max 32A
1x CEE 1-32, fixed
|
| |
|
|
Output
|
Output voltage
Max. output
Max. output/ port
Connectors
|
AC 100 - 240 V~, 50/60Hz
32A, 7360W
10A
16x C13
|
| |
|
|
Remote control
|
Network
Cascade input/output
Temperature sensor
Other sensors
Protocols
|
1x RJ45, 10/100M
2x RJ45, 10/100M
1x RJ11
6x RJ11
TCP/IP, UDP, HTTP, HTTPs, DHCP, SNMP, Mail
|
| |
|
|
Safety
|
Over power protection
|
+
|
| |
|
|
Environmental
|
Temperature
Humidity
|
0°C - 50°C (Operation)
-20°C - 60°C (Storage)
0% - 80% (Operation, non condensing)
0% - 85% (Storage, non condensing)
|
| |
|
|
Scope of delivery
|
|
PDU
Power cord CEE 1-32, fixed
Temperature sensor
Short instructions, English + German
|
| |
|
|
Warranty
|
|
24 Months
|
| |
|
|
Logistic data
|
Dimension
Net weight
Gross weight
Article number
GTIN
Packing unit
|
1126 x 66 x 44.5 mm
3.000 kgs
3.470 kgs
88887395
4260455648905
1 pcs/ 9 pcs
|
