Features
|
|
700 Watt power supply according Intel 2.4
High efficiency, more than 85%
|
| |
|
|
Input
|
Voltage
Frequency
Current
|
AC 230 V~
50 Hz
3A @230V
|
| |
|
|
Output
|
Output voltage
+ 3.3V
+ 5V
+ 12V
- 12V
+ 5Vsb
Total power
Power 3.3V + 5V
Power 12V
|
Current
max. 15A
max. 16A
max. 30A
max. 0.8A
max. 2.5A
max. 700W
max. 120W
max. 360W
|
| |
|
|
Safety
|
Over voltage protection
Under voltage protection
Short circuit protection
Over current protection
|
+
+
+
+
|
| |
|
|
Economic data
|
Efficiency
@ 20% load
@ 50% load
@ 100% load
|
88.8 %
89.1 %
85.3 %
|
| |
|
|
Environmental
|
Temperature
Humidity
|
0°C - 40°C (operating)
-35°C - 70°C (storage)
10% - 90% (operatig, non condensing)
50% - 95% (storage, non condensing)
|
| |
|
|
Scope of delivery
|
|
Power supply
Power cord
|
| |
|
|
Warranty
|
|
24 Months
|
| |
|
|
Logistic data
|
Dimension
Net weight
Gross weight
Article number
GTIN
Packing unit
|
150 x 140 x 86 mm
1.10 kg
1.26 kg
88882244
4260455649650
1 pcs
10 pcs (carton)
320 pcs (EU pallet)
|
