3U-30765
The 3U-30765 is a versatile 3U server case with removable HDD cages.
Up to five hard disks fit into each HDD-cage, without screw or tool. One 120mm fan in each HDD-cage cooles the hard disks and is exchangeable without open the case.
If not so many 3.5" drives are required, the HDD-cage can be removed from the housing and three 5.25" drives can be installed instead of each HDD-cage.
Three 120mm fans on the center bar of the case increase the airflow and protect your components from overheating. In addition, two 60mm fans are installed in the rear panel, which together ensure a perfect airflow.
Features |
5x 120mm fans and 2x 60mm fans
|
|
Size |
MainboardCase |
Mini-ITX, Micro-ATX, ATX, E-ATX, SSI CEB, SSI EEB
|
HDD/ ODD Mounting space |
5,25" external3,5" external3,5" or 2,5" external3,5" internal2,5" internal3,5" or 2,5" internal |
3 or 6 (by removing of one or two HDD-cages)--10 (5 per HDD-cage)-4 |
Front connectors |
USB A 3.0USB A 2.0USB Type CHeaphoneMicrophoneCard Reader |
1x 3.2 Gen11---- |
Mounted fans |
200mm140mm120mm
|
--2 Front , 2pin to Molex
|
Further mounting options |
Power supplyCPU coolerGraphic adapterFans |
ATXmax. 105mmmax. 350mm2x 60mm (rear) |
Scope of delivery
|
|
Case
|
Warranty |
|
24 Months |
Logistic data |
Net weightGross weightArticle numberGTINPacking unit |
12.2155 kgs14.750 kgs8888738542604556483631 pcs
|
Actually no tests available
 |
