2U-2504
The IPC 2U-2504 is a perfect case for a cost-efficient Mini Server System. Using high-level material combined with excellent workmanship we created a variable and reliable industrial case.
So the 2U-2504 supports ATX power supplies (only with 80mm fan), up to four 2,5“/3,5“ Hot-Plug hard disks, two internal 2,5“ devices, one external 5,25“ devices and MiniITX and mATX mainboards.
Furthermore the case has two 60mm fans and two USB 3.2 Gen1 front ports.
Features |
4x Hot-Swap HDD frames
|
|
Backplane |
Quantity BackplanesQuantity hard disksTransfer speedData connectionElectrical connection |
22/ Backplane6 Gb/s2x SATA/ Backplane1x Molex/ Backplane |
Size |
MainboardCase |
Mini-ITX, Micro-ATX (max. 244 x 244mm - 9,6" x 9,6")480 x 527 x 89mm (WxDxH) |
HDD/ ODD Mounting space |
5,25" external3,5" external3,5" or 2,5" external3,5" internal2,5" internal3,5" od. 2,5" intern |
1-4 (Hot-Swap)-2- |
Front connectors |
USB A 3.0USB A 2.0USB Type CHeadphoneMicrophoneCard Reader |
2x 3.2 Gen1----- |
Mounted fans
|
200mm140mm120mm80mm60mm |
----2 (Molex connector) |
Further mounting options |
Power supplyPCIeCPU coolerGraphic adapterFans |
ATX with 80mm fan4max. 60mmmax. 250mm (Low-Profile)- |
Scope of delivery
|
|
Case
|
Warranty |
|
24 Months |
Logistic data
|
Net weightGross weightArticle numberGTINPacking unit |
7,71 kgs10,53 kgs8888733442604556464131 pcs
|
