EPS-650W

Energon EPS-650W - More power, less cost

For customers who needs high wattage but don’t want to spend that much money on a power supply the EPS-650W is the perfect choice. Despite the low price, Inter-Tech has made no compromise in technical or quality aspects.

Equipped with active PFC, a super silent fan and P4/EPS connectors the EPS-650W provides all modern extras. PCI-Express connectors for more demanding graphic cards and 4 separated 12V-lines for a more stable power supply makes this device a real option for every gaming or graphic computer system. The sturdy and black finishing as well as long and flexible cables completes this excellent package.

POWER & EFFICIENCY
Output 650Watt
Efficiency

at 20%82.50%
at 50%85.50%
at 100%83.70%

ATX-Version 2.2
CONNECTORS
Mainboard 20+4Pin 1x
4Pin / 4+4Pin / 8Pin 12V /  /
PCI-Express 6+2Pin 1x
PCI-Express 6Pin
IDE 4Pin (Molex) 4x
S-ATA 4x
Floppy 1x
Fan monitoring
OTHER DATA
Fans / -size 1x 120mm
Fan control auto
Full Range Input auto
80PLUS® Certificate
Noise level 19-21dB
Dimension (h/w/d) 86 x 150 x 140mm
Guarantee 24 months
Safeties OVP, SCP , OPP, UVP, OS
SCOPE OF DELIVERY & FEATURES
Scope of delivery

Power supply EPS-650W

Retail package

screws

power cable

manual

LOGISTICAL DATA
Shipping Unit 1 Pcs
Packing Unit 10 Pcs
EU palett 280 Pcs
Weight net = 1.27kgs
gross = 1.60kgs
Item number 88882022
EAN-Code 4260133121157



PERFORMANCE DATA

AC Input 115V/230V  3A  50/60Hz
DC Output + 3.3V + 5V + 12V1 + 12V2 + 12V3 + 12V4 - 12V + 5VSB
Energon
EPS-650W
Max.
Current
28A 28A 18A 18A 18A 18A 0.8A 2.5A
Max.
Combined
Power
150W 550W 20W
650W

CABLE CONFIGURATION

Data sheet Energon EPS-650
Download
Picture package Energon EPS-650
Download

* You need a PDF reader to read these documents
* Pictures and drivers are always packed as Zip. You need to unzip them before using.
