EPS-650W CM
The Energon EPS-650W CM Power Supply with Cable Management
Based on our top selling product Energon EPS-650W, Inter-Tech designed the EPS-650W CM to satisfy the growing demand of the market for power supplies with flexible cable management. Except the basic 20+4 mainboard and P4+4 connectors which are bounded all other connectors are modular.
Additionally, the EPS-650W CM is equipped excellently with a super silent 135mm fan, a PCI-Express and a big array of S-ATA and IDE connectors.
Two standard S-ATA to IDE adapters makes the EPS-650W CM even more flexible in its range of use.
| POWER & EFFICIENCY | |
|---|---|
| Output | 650Watt |
| Efficiency |
|
| ATX-Version | 2.2 |
| CONNECTORS | |
| Mainboard 20+4Pin | 1x |
| 4Pin / 4+4Pin / 8Pin 12V | / / |
| PCI-Express 6+2Pin | 1x |
| PCI-Express 6Pin | |
| IDE 4Pin (Molex) | 2x |
| S-ATA | 4x |
| Floppy | 1x |
| Fan monitoring | |
| Cable management | |
| OTHER DATA | |
| Fans / -size | 1x 135mm |
| Fan control | auto |
| Full Range Input | auto |
| 80PLUS® Certificate | |
| Noise level | 19-21dB |
| Dimension (h/w/d) | 86 x 150 x 160mm |
| Guarantee | 24 months |
| Safeties | OVP, SCP , OPP, UVP, OS |
| SCOPE OF DELIVERY & FEATURES | |
| Scope of delivery |
Power supply EPS-650W CM Retail package 2x S-ATA to IDE Adapter Cable Strips Thumbscrews Power Cord User manual in German |
| LOGISTICAL DATA | |
| Shipping Unit | 1 Pcs |
| Packing Unit | 5 Pcs |
| EU palett | 210 Pcs |
| Weight | net = 1.32kgs gross = 1.88kgs |
| Item number | 88882090 |
| EAN-Code | 4260133123458 |
PERFORMANCE DATA
| AC Input | 115V/230V 3A 50/60Hz | ||||||||
| DC Output | + 3.3V | + 5V | + 12V1 | + 12V2 | + 12V3 | + 12V4 | - 12V | + 5VSB | |
| Energon EPS-650W CM |
Max. Current |
28A | 28A | 18A | 18A | 18A | 18A | 0.8A | 2.5A |
| Max. Combined Power |
150W | 550W | 20W | ||||||
| 650W | |||||||||
CABLE CONFIGURATION
